OET-251H-M
产品描述
Wall Mounted Mifare Card Reader
关键特性
- Supports Wiegand/RS-485 data output.
- Built-in buzzer.
- Supports indoor and outdoor application.
- Stability, sensitivity, and responsiveness.
- Supports ISO 14443-A and ISO 14443-B protocols.
技术规格
基本业务
| Reading Time | < 1s |
| Card Type | Mifare card |
硬件规格
| Operating Frequency | 13.56MHz |
| Interface | Wiegand 26/34, RS485 |
| Material | PC |
| Dimensions (L x W x H) | 129*88*21mm |
| Weight | 134g |
| Mount Method | 115*73mm junction box, 86*86mm junction box |
| Operating Temperature | -30°C to 65°C |
| Operating Humidity | 10% to 90% |
| Storage Temperature | -40°C to 65°C |
| Indicator | Steady blue: Normal operation;Steady green for 1s: Card authentication succeeded;Steady red for 1s: Card authentication failed |
| Power Consumption | 0.732W |
| Operating Voltage | DC 12V ± 25% |
| Operating Current | 61mA |
| Reading Distance | IC card: max. 5cm |
| Authentication Mode | Card |
| Protection Level | IP65 |
