MW3575-U-CA
产品描述
I5 Processor Pluggable PC Module(Win11 System is Not Activated)
关键特性
- Slim and compact design takes up less space.
- Compliant with OPS standards, ideally suited for smart interactive displays.
- DP/HDMI interface supports synchronous and asynchronous display.
- 4K UHD display.
- WLAN with hotspot support.
- Intelligent fan control.
技术规格
BOM
| BOM | 9801C2S9 |
WLAN
| WLAN | 1 × M.2 2230 (Support Cnvi and WIFI 6E, BT 5.2) |
System
| CPU | I5-12450H |
| Cores | 8 |
| Threads | 12 |
| CPU Frequency | 2.0 GHz |
| Max. Turbo Frequency | 4.4 GHz |
| RAM | 8 GB DDR4, support for expansion up to 32 GB |
| ROM | 256 GB SSD |
| Operation System | Windows 11 Enterprise (not activated) |
常规参数
| Power Supply | DC 19V, supplies power via OPS interface |
| Overall Power Consumption (W) | ≤85 |
| Standby Power Consumption (W) | ≤35 |
| Product Dimensions (W × H × D) (mm) | 195 × 180 × 30 |
| Package Dimensions (W × H × D) (mm) | 306 × 276 × 78 |
| Weight (kg) | Net Weight: 0.9 |
| Operating Temperature | -10°C to 50°C |
| Operating Humidity | 10% to 90% RH |
| Storage Temperature | -20°C to 70°C |
| Storage Humidity | 10% to 90% RH |
接口参数
| USB | 4 × USB 3.0, 2 × USB 2.0, 1 × USB 3.0 USB Type-C |
| Audio | 1 × MIC, 1 × Line Out |
| HDMI | 1 × HDMI (Max. Resolution: 3840 × 2160@60 Hz) |
| DP | 1 × DP (Max. Resolution: 3840 × 2160@60 Hz) |
| Network | 1 × RJ45 (10/100/1000M) |
| Antenna | 2 × dual-band antenna |
| Reset Key | 1 × Reset Key |
| Power on/off Switch | 1 × power on/off switch |
| Power Indicator | 1 × power indicator |
