24英寸LED显示器
产品描述
24英寸LED显示器
关键特性
- ● 真彩显示，色彩还原完美
- ● 广视角：178°(水平)/ 178°(垂直)
- ● 任何视角均无色彩偏移
- ● 专属菜单设计，操作简便
- ● 支持7*24小时工作，低功耗
- ● 自适应信号识别
- ● VESA壁挂支架
- ● 高保真数字处理，呈现清晰生动的画面
- ● 专业散热设计，延长设备使用寿命
- ● 屏幕可减少蓝光，保护眼睛
- ● 无波纹，采用直流平滑调光，消除屏幕闪烁
- ● 三面超薄设计，最薄处仅2.8mm
- ● 高透光率，亮度均匀，色彩丰富，色域广
技术规格
| Model | MW3224-V |
| Panel | |
| Backlight | ELED |
| Panel Size | 24" |
| Pixel Pitch (H × V) (mm) | 0.2745 x 0.2745 |
| Resolution | 1920 × 1080 |
| Color Support | 16.7 M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 1200:1 |
| Refresh Rate | 60 Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Display Size (mm) | 527.04 x 296.46 |
| Operation Hour | 24/7 |
| Bezel Width | 2.00mm (top/left/right), 20.60mm (bottom) |
| Color Gamut | 72% NTSC |
| Surface Treatment | Haze 25%, 3H |
| Interface | |
| Video Input | 1 x VGA, 1 x HDMI |
| Audio Input | 1 x 3.5mm Mini-Jack |
| Speaker | |
| Speaker | 2 x 1.5 W |
| VESA | |
| VESA (mm) | 100 x 100 |
| Wall-mounted Thread | 4-M4 Threaded Hole, Depth 10mm |
| OSD | |
| Multi-Language | 8 (English, French, Spanish, German, Russian, Korean, Japanese, Simplified Chinese) |
| General | |
| Input Voltage | DC 12 V, 2 A |
| Typical Power Consumption (W) | ≤24 (On) |
| Standby Power Consumption (W) | ≤0.5 (Standby) |
| Product Dimensions (W × H × D) (mm) | 541.8 x 412.6 x 200 (With Pedestal) |
| Package Dimensions (W × H × D) (mm) | 606 x 405 x 125 |
| Weight (kg) | Net Weight: 3.3 Gross Weight: 4.6 |
| Operating Temperature | 0°C ~ 40°C |
| Operating Humidity | 20% ~ 85% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10% ~ 90% (No Condensation) |
| Standard | HDMI Cable, Power Cable, Adapter, Pedestal, Quick Guide |
| Material | ABS |
| Lifetime (h) | 30000 |
| Certifications | CE/FCC |
| MTBF (h) | 50000h |
